ETH Switch & Industrial Switch

Key features:

• Installation Method: DIN Rail Mount

• Protection Level: IP30, reduces dust impact

• Industrial-grade operating temperature: -40°C to 75°C

• 8K MAC addresses; static MAC addresses, MAC address filtering, dynamic MAC binding for address table management

• MAC address auto-learning, auto-aging, and aging time settings

• IEEE 802.1Q VLAN, flexible VLAN segmentation based on user needs(for managed switch)

• Voice VLAN for QoS configuration, prioritizing voice data flow and ensuring call quality(for managed switch)

• QoS: Supports port-based, 802.1P-based, and DSCP-based priority modes, with queue scheduling algorithms including Equal, SP, WRR, SP+WRR

• ACL: Filtering of data packets through configurable matching rules, actions, and time permissions, providing flexible security access control policies

• IGMP V1/V2 multicast protocol, supports IGMP Snooping to meet HD video surveillance and video conferencing needs

• Multicast VLAN and multicast filtering for efficient data transmission, bandwidth saving, and reduced network load

• 802.1X authentication for LAN computer access, with port authorization control based on authentication results

• STP/RSTP/MSTP spanning tree protocols to eliminate Layer 2 loops and enable link redundancy

• ERPS rapid ring protocol with a recovery time of 20ms (currently supports single ring only)

• Ingress/egress bandwidth control based on port

• Static and dynamic link aggregation for increased link bandwidth, load balancing, link redundancy, and improved link reliability

• Web management, CLI (Console, Telnet), SNMP (V1/V2/V3) for diverse management options

• Secure management with HTTPS, SSL V3, TLSV1, SSHV1/V2 encryption

• RMON, system logs, and port traffic statistics for network optimization and improvements

• Cable detection, Ping, and Tracert tests to easily analyze network faults

• LLDP for network management systems to query and assess link communication status

• CPU monitoring, memory monitoring, Ping, Tracert tests, and cable detection
